Instruction Manual: Kongsberg AutoChief C20 MAN MC Engines Fixed Pitch Propeller

Книга на английском языке
This instruction manual for the AutoChief®C20 Propulsion Control System is intended as a guide for the ships personnel while operating the engine on a daily basis in transit between ports, assuming a standard configuration for MAN BW MC Engines with Fixed Pitch Propeller. Any significant changes in system parameters and maintenance should be handled by design and installation engineers at the shipyard, in accordance with installation drawings applicable to the vessel.

Contents
Admonitions
Glossary
1 About this manual
2 Functional description
2.1 Remote Control System Functional Description
2.2 AutoChief®C20 Control Panel (ACP)
2.3 AutoChief®C20 Combined Lever and Telegraph Unit (LTU)
2.4 AutoChief®C20 Bridge Wing Control Unit (BWU)
2.5 AutoChief® C20 Pushbutton Telegraph (PBT)
2.6 AutoChief® C20 Start- Stop & Speed-set lever
2.7 AutoChief®C20 Order Printer
2.8 Indication Panel Unit
2.9 Emergency control El.box standard
2.10 Remote control system functions
2.11 Safety system functions
2.12 Distributed Processing Unit (DPU)
3 Operation
3.1 Operation from Bridge
3.2 Operation from Bridge Wing
3.3 Operation from EC'R
3.4 Operation from Local Stand
3.5 Command Transfer
3.6 Advanced operation from Bridge and EC'R
4 Maintenance
4.1 Preventive maintenance
4.2 Troubleshooting
4.3 Replacement of Units
5 As built configuration
